Ortofon DJ Concorde MkII Club Cartridge

$329.00
Available from Supplier

We can order in this item from our supplier, it usually ships from our store in 3-4 business days if the supplier has this item in stock.

Model
Qty
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

Concorde MKII Club

The Concorde CLUB delivers exceptional sound quality and an elevated output voltage for a powerful, energetic audio experience. With its outstanding specifications and remarkable sound profile, the CLUB stands as a prime selection for Club DJs across various settings – be it the studio, broadcast, or club venues.



Stylus

The CLUB features a Special Elliptic stylus that allows for detailed sound quality. The Special Elliptic stylus fits better in the groove and has more contact area with the groove itself, extracting more intricate details, than is possible with a Spherical diamond.



Output

The Concorde CLUB presents outstanding sound quality and an increased output of 8 mV, translating into a robust and vibrant audio performance. This heightened output voltage significantly reduces the demand for preamp gain, resulting in a cleaner and more faithful sound reproduction. Additionally, this attribute minimizes susceptibility to feedback, a particularly advantageous feature when performing in dynamic live environments.

  • The CLUB features a Special-Elliptic stylus that allows for detailed sound quality: Special-Elliptic stylus fits better in the groove and therefore has more contact area with the groove itself, extracting more intricate details, than is possible with a spherical diamond.
  • The CLUB’s 8 mV output voltage requires less gain from the preamps, providing cleaner sound reproduction and less susceptibility to feedback in live environme

Channel balance at 1 kHz

  • 1 dB

Output voltage at 1 kHz, 5cm/sec

  • 8 mV

Channel separation at 1 kHz

  • 25 dB

Tracking ability at 315Hz

  • 100 μm

Compliance, dynamic, lateral

  • 14 μm/m N

Cantilever material

  • Aluminium

Stylus type

  • Special Elliptical diamond

Stylus tip radius

  • r/R 13/25 μm

Tracking force range

  • 2 - 4 g

Tracking force, recommended

  • 3 g

Internal impedance, DC resistance

  • 1000 Ohm

Recommended load impedance

  • 200-600 pF

Cartridge weight

  • 18,5 g

Recommended load resistance

  • 47 kOhm

Internal inductance

  • 650 mH

Replacement stylus

  • Stylus CC MKII Club
