Ortofon DJ Concorde MkII Scratch Cartridge

$289.00
Available from Supplier

We can order in this item from our supplier, it usually ships from our store in 3-4 business days if the supplier has this item in stock.

Model
Qty
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

Concorde MKII Scratch

The Concorde Scratch is intended especially for the disciplines of scratch and back-cueing. It allows turntablist and scratching DJs to achieve new levels of performance with unprecedented tracking ability and extra high output.



Stylus

DJs prefer spherical styli, as they preserve more of the groove over back-cueing and scratching. For DJs that require increased tracking ability, the SCRATCH is up to the task. The Scratch has a supreme ability to trace the grooves of the records and is tailored specifically for scratch.



Output

Due to its very high output 10 mV, it is perfect for scratch of all music with deep bass frequences. With solid bass reproduction and extended highs, the SCRATCH is great for any style, providing energetic sound. Maximum scratch performance guaranteed!



Awesome freestyle with the Scratch

Multiple Russian DMC Champion DJ CHELL, freestyling with the Concorde Scratch MKII. The Scratch has been personalized with a yellow fingerlift.

  • The SCRATCH is intended especially for scratching and back-cueing. The SCRATCH uses spherical styli, as they preserve more of the groove over backcueing and scratching.
  • For DJs that require increased tracking ability, the SCRATCH is up to the task. The Scratch has a supreme ability to trace the grooves of the records and it is tailored specifically for scratch.
  • Due to its very high output 10 mV, it is perfect for scratch of all music with deep bass frequencies. With solid bass reproduction and extended highs, the SCRATCH is great for any style, providing energetic sound. Maximum scratch performance guaranteed!

Channel balance at 1 kHz

  • 1 dB

Output voltage at 1 kHz, 5cm/sec

  • 10 mV

Channel separation at 1 kHz

  • 22 dB

Tracking ability at 315Hz

  • 120 μm

Compliance, dynamic, lateral

  • 14 μm/m N

Cantilever material

  • Aluminium

Stylus type

  • Spherical diamond

Stylus tip radius

  • R 18 μm

Tracking force range

  • 3 - 5 g

Tracking force, recommended

  • 4 g

Internal impedance, DC resistance

  • 1200 Ohm

Cartridge weight

  • 18,5 g

Recommended load resistance

  • 47 kOhm

Internal inductance

  • 850 mH

Recommended load capacitance

  • 200-400 pF

Replacement stylus

  • Stylus CC MKII Scratch
